ENGINE
g. If the pressure plate stroke is out of specifica- b. Start the engine.
tion, repeat steps (j) to (l) in the procedure for c. Shift the transmission from neutral to 1st gear
step “2. Bleed” until clutch pressure plate and back to neutral ten times.
stroke is within specification. d. Shift the transmission into 1st gear, and then
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲ apply the rear brake.
4. Install: NOTE:
• Swingarm If the engine stalls, restart the engine, let it idle
Refer to “SWINGARM” on page 4-91. for at least 90 seconds, and then repeat steps (c)
• Rear wheel and (d).
Refer to “REAR WHEEL” on page 4-24.
• Air filter case ▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
Refer to “GENERAL CHASSIS” on page 4-1. 3. Check:
• Starting-off performance of vehicle
ET3P66067 Abnormal vehicle vibration/abnormal start-
CHECKING THE VEHICLE AFTER ing-off performance/sudden acceleration
BLEEDING THE HYDRAULIC CLUTCH compared to before the hydraulic clutch sys-
SYSTEM (FJR13AE only) tem was serviced → Select diagnostic code
1. Check: No. Sh_ _66 in the diagnostic mode and op-
• Rear wheel drag torque erate the hand shift lever switch (shift up) two
Rear wheel does not rotate/drag torque does times.
not progressively increase in the following or- Refer to “Diagnostic code table (Diagnostic
der: neutral, 1st gear, and when rear wheel code No. Sh_ _66)”.
starts to rotate in 1st gear → Check the pres- ▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
sure plate stroke. a. Place the vehicle on the centerstand.
Refer to “BLEEDING THE HYDRAULIC b. Start the engine and warm it up until at least
CLUTCH SYSTEM (FJR13AE)” on page three segments appear on the coolant tem-
3-19. perature meter “1” as shown in the illustra-
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼ tion.
a. Place the vehicle on the centerstand.
b. Turn the main switch to “ON”. 1
c. Shift the transmission into neutral, and then
rotate the rear wheel by hand.
c. Shift the transmission into 1st gear, and then
slowly turn the throttle grip and check that the
rear wheel rotates.
d. Check that the transmission can be shifted
d. Shift the transmission into 1st gear, and then into 2nd gear.
rotate the rear wheel by hand. e. Shift the transmission into neutral, and then
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲ raise the centerstand.
2. Check: f. Shift the transmission into 1st gear, and then
• Shift operation slowly turn the throttle grip and check the
Engine stalls → Check the pressure plate starting-off performance of the vehicle.
stroke. ▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
Refer to “BLEEDING THE HYDRAULIC
CLUTCH SYSTEM (FJR13AE)” on page
3-19.
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Place the vehicle on the centerstand.
3-21
